Carbon Removal Method

Biochar

Biochar is a powerful environmental and climate ally due to its permanence and the environmental benefits it delivers. This scalable solution is both cost-efficient and effective at storing carbon for hundreds to thousands of years when added to soils or buried at depth.

Introduction

What is biochar?

Biochar is a charcoal-looking, carbon-rich substance that is produced by heating organic materials, such as wood, crop residues, or manure – a process called pyrolysis.

The term ‘biochar’ can describe any organic material that has been carbonised under high temperatures (300-800°C) in the presence of little or no oxygen. The process results in a stable, carbon-rich material that can be safely stored for hundreds to thousands of years.

Because it can be made from almost any type of biomass – including waste materials – biochar is recognised for its potential environmental benefits, particularly in soil health and carbon sequestration.

By soaking it in nutrient-rich solutions or combining it with compost, manure, or other organic fertilisers, biochar can be ‘charged’ with nutrients. The charged biochar can then release those nutrients slowly into the soil, acting like a controlled-release fertiliser. This ‘circular’, or zero-carbon fertiliser boosts soil health, improving soil structure, water retention, and microbial activity.

Further, the production of biochar also sequesters carbon from organic materials, reducing overall carbon emissions. When biochar is used in fertilisers, it can offset the carbon emissions typically associated with synthetic fertilisers. This makes the fertiliser system more sustainable and potentially carbon-neutral.

Biochar is a great example of human engineering and nature working together to store carbon. It is a stable solution that can be circular. While accessibility of biomass is a limiting factor, current agricultural systems produce many excess products, making biochar highly scalable

Read more

Supplier: Carboneers
Method overview

The Steps

The three general steps in biochar production and storage are outlined below. Biochar is a prime example of a hybrid carbon removal method as both natural and engineered processes are involved.

Biomass

CO₂ is trapped by plants and converted to carbon-rich biomass in a process called photosynthesis.

Pyrolysis

Biomass is heated to between 300 and 800°C in full or partial absence of oxygen to produce the biochar and other by-products, some of which are suitable as input for renewable energy generation.

Use

Biochar is primarily used as a soil amendment for the improvement of agricultural and forest soils, but it can also be used in the construction industry.

Capture & Storage

How it works

Carbon Sequestration

The sequestration step in carbon dioxide removal via biochar production is facilitated by photosynthesis. Plants, such as agricultural crops and trees in forests, take up water from the soil and absorb CO₂  from the atmosphere.

Using energy from the sun, a green pigment called chlorophyll converts the water and CO₂  to oxygen and glucose. The oxygen is released into the atmosphere and the glucose goes on to nourish the growing plant and create biomass. Large quantities of waste biomass is produced in agriculture, forestry, food processing and manufacturing, and in municipalities, and this biomass is suitable for biochar manufacturing.

Pyrolysis

In the absence of oxygen, the pre-treated waste biomass that otherwise would have rotted and reemitted CO₂  to the atmosphere, is subjected to thermal decomposition through high pressure and temperature in a reactor. This is pyrolysis.

This process generates three products: synthetic gas, bio-oil, and biochar. The biochar is separated from the other by-products in a cyclone, while the other products can be used for energy recovery.

Among the different types of pyrolysis, slow pyrolysis yields the highest proportion of biochar due to the lower temperatures (300-500°C), slower heating rates, and longer residence time of the biomass in the reactor.

Carbon Storage & Use

The biochar produced from pyrolysis is generally very stable and contains >65% carbon. This biochar could just sit in storage anywhere for centuries but there are opportunities to optimise its use.

For example, it can be used as a soil amendment in agriculture and forestry, where it confers many co-benefits while safely and permanently storing most of the biochar-carbon. Biochar can alternatively be incorporated into long-lasting building materials, such as plaster, concrete, bricks, and insulation.

WHY USE THIS METHOD

An accessible, scalable, circular solution

Stabilizing carbon in biochar is a perfect example of how human engineering and nature can work together. If we can produce and protect this biochar-carbon at scale and in a responsible manner, significant positive climate, social, and economic impacts are possible.

The technology and knowledge are in place to make this work, but significant financing is required to achieve the level of production necessary to realize these impacts.

EVALUATION

Climate Impact

74
Points out of 100

(median score)
EVALUATION

Climate Impact

The majority of biochar’s climate change mitigation potential can be attributed to its slower composition compared to the raw material from which it is produced.



Biochar could remove and securely store CO₂ on the gigatonne scale in the near future (estimates from leading researchers are between ~2-3.7 Gt CO₂ e per year), but only if barriers, such as financing, can be overcome. Aside from this, biochar has a positive climate impact via some secondary mechanisms.



N20 and CH4 emissions are reduced, plant growth is promoted, leading to a positive feedback of increased CO₂ removal from the atmosphere, while reducing emissions from fertilizer use.

74

Median score

93

Minimum score

97

Maximum score

5

Count

36 data points
EVALUATION

Co-Benefits

63
Points out of 100

(median score)
EVALUATION

Co-Benefits

When used as a soil amendment, biochar can improve fertilizer use efficiency and soil fertility by reducing nutrient leaching and mitigating gaseous nitrogen losses.



Other benefits include enhanced rates of pesticide and chemical degradation, and improved soil structure and water holding capacity. Biochar can also contribute to the greening and improvement of the construction industry. It can increase the strength of cement and it is an excellent insulating material for buildings as it maintains stable humidity levels.



Lastly, one of biochar’s greatest attributes is that it can be produced anywhere with the right investment, and so, could provide a meaningful form of income for many rural communities around the world.

63

Median score

23

Minimum score

52

Maximum score

11

Count

36 data points
Deep dive

The benefits: How biochar production support the fight against climate change

Unlike conventional forms of organic matter (such as garden compost), biochar takes a very long time to decompose. The decomposition process can take centuries – even millennia. This means that biochar has great potential to store carbon in the soil, helping to reduce atmospheric carbon dioxide levels and mitigate climate change.

In addition to this, there are many other key benefits of biochar production that support the fight against climate change. These include:

  • Soil health improvement: Biochar application enhances soil fertility by retaining nutrients and water, reducing the need for chemical fertilisers. It also provides a habitat for beneficial soil microorganisms that contribute to nutrient cycling and plant health, and its porous nature helps improve soil structure, increasing aeration and water infiltration.
  • Water retention: The porous structure of biochar enables it to retain water, making it particularly useful in arid and drought-prone regions.
  • Reduction of greenhouse gasses: When added to soil, biochar can reduce emissions of nitrous oxide by improving soil conditions and reducing the need for fertilisers.
  • Pollution remediation: Biochar can absorb heavy metals and organic pollutants from soil and water, helping to remediate contaminated environments.
  • Energy production: During the pyrolysis process, gasses and oils are also produced. These can be used as biofuels, providing an additional source of energy in the process.

Artisanal vs industrial biochar – what is the difference?

Biochar production can vary depending on the scale and methods used. The primary differences between artisanal and industrial biochar lie in the following four areas:

  1. Production methods: Artisanal biochar can be made from a wide range of feedstock waste, but is typically made from locally available organic materials and produced on a smaller scale using accessible, low-tech methods and lower temperatures. Industrial biochar can also be made from a wide range of feedstocks, including agricultural waste and industrial byproducts, and is produced on a much larger scale using higher temperatures and often industrial byproducts.
  2. Quality control: Artisanal biochar production can have varying pyrolysis conditions, which can lead to slightly shorter or more variable storage times. Industrial biochar is typically tested and certified to meet specific standards or regulatory requirements and tends to be more reliable for commercial applications.
  3. Scale and cost: Due to its small-scale nature, artisanal biochar production is limited and might not meet the demands of large agricultural or industrial projects. However, it can also be less expensive to produce. Industrial production can produce large quantities of biochar to meet commercial demands. However, it requires advanced technology and infrastructure and can therefore be more expensive.
  4. Environmental impact: Artisanal biochar is typically produced on a smaller scale using local materials, which can potentially lead to a lower carbon footprint. The production technologies used in industrial biochar production often include emission controls, reducing the environmental impact of the production process.

In short, both artisanal and industrial biochar typically use locally available organic matter and a wide range of feedstock waste. However, artisanal biochar is more locally orientated and produced on a smaller scale. It is made using lower temperatures it can also be more sustainable and accessible to small farmers and communities.

Industrial biochar, on the other hand, is produced on a larger scale, ensuring large quantities for commercial and industrial use. However, its production also requires significant investment and infrastructure.

Overall, by enhancing soil health, sequestering carbon, and reducing the need for chemical fertilisers, biochar offers many environmental benefits, making it an important asset in the fight against climate change and a key resource on the road towards net zero.
